Rolling Stock Manufacturing

A wide variety of parts that make up a locomotive, a passenger car or a railcar tanker require both manual and automated welding operations on a wide variety of materials and wall thicknesses. Each of these parts – from the underframe, the roof, sides and body shell to the bogie and railcar tankers – presents unique challenges in obtaining high-quality welds. We have the right consumables for the wide variety of base materials used in the industry: unalloyed, high-strength steel, stainless-steel and aluminum.

Welding Solutions for increased Track Performance

Railway tracks are inseparable from weld seams. The safety of rail traffic depends to a large extent on the quality of these welds. voestalpine Bohler Welding can offer the entire portfolio of welding products and solutions to ensure maximum service life of tracks and turnouts.

We have the necessary knowledge and experience to solve all welding-related problems inside and outside the tracks. Not only do we offer in-track welding solutions, such as deposition welding of grooved rails, but we also provide trainings in the field of rail and turnout welding.

Product Overview

Welding Consumables for the Railway Industry

Product Name Industry Application Base Material / Consumable Alloy type AWS EN/ISO Process
Böhler EMK 6 Boggies/Waggons up to 420 Mpa YS A5.18: ER70S-6 14341-A: G 42 4 M21 3Si1 GMAW
Böhler EMK 6 NC Boggies/Waggons up to 420 Mpa YS A5.18: ER70S-6 14341-A: G 42 4 M21 4Si1 GMAW
Böhler EMK 8 Boggies/Waggons up to 460 Mpa YS A5.18: ER70S-6 14341-A: G 46 4 M21 4Si1 GMAW
Böhler EMK 8 NC Boggies/Waggons up to 460 Mpa YS A5.18: ER70S-6 14341-A: G 46 4 M21 4Si1 GMAW
diamondspark 46 MC Boggies/Waggons up to 460 Mpa YS A5.18/SFA-5.18: E70C-6M H4 17632-A: T 46 3 M M21 1 H5 MCAW
Böhler EMK 6 Boggies/Waggons up to 420 Mpa YS A5.18: ER70S-6 14341-A: G 42 4 M21 3Si1 GMAW
Böhler EMK 6 NC Boggies/Waggons up to 420 Mpa YS A5.18: ER70S-6 14341-A: G 42 4 M21 4Si1 GMAW
Böhler EMK 8 Boggies/Waggons up to 460 Mpa YS A5.18: ER70S-6 14341-A: G 46 4 M21 4Si1 GMAW
Böhler EMK 8 NC Boggies/Waggons up to 460 Mpa YS A5.18: ER70S-6 14341-A: G 46 4 M21 4Si1 GMAW
diamondspark 46 MC Boggies/Waggons up to 460 Mpa YS A5.18/SFA-5.18: E70C-6M H4 17632-A: T 46 3 M M21 1 H5 MCAW
diamondspark 52 MC Boggies/Waggons up to 460 Mpa YS A5.18/SFA-5.18: E70C-6M H4 17632-A: T 46 4 M M21 1 H5, T46 5 M M20 1 H5 MCAW
diamondspark 52 RC Boggies/Waggons up to 460 Mpa YS A5.20/SFA-5.20: E71T1M/T-9M/T-12M JDH4 / E71T1C/T-9C/T-12C DH4 17632-A: T46 4 P M 21 1 H5, T46 2 P C1 1 H5 FCAW
Böhler Ni Cu 1-IG Boggies/Waggons weather resistant steels A5.28: ER80S-G 14341-A: G 42 4 M21 Z3Ni1Cu GMAW
Union K 5 Ni Boggies/Waggons up to 500 Mpa YS A5.28: ER 80S-G 14341-A: G 50 5 M21 3Ni1, G 46 3 C1 3Ni1 GMAW
BÖHLER 2,5 NI-IG Boggies/Waggons 2.5 nickel steels, ASTM A203 GrB A5.28: ER80S-Ni2 14341-A: G 46 8 M21 2Ni2 GMAW
Union NiMoCr Boggies/Waggons up to 690 Mpa YS A5.28: ER100S-G, (ER100S-1 (mod)) 16834-A: G 69 6 M21 Mn3Ni2,5CrMo GMAW
Union X 85 Boggies/Waggons up to 790 Mpa YS A5.28: ER110S-G 16834-A: G 79 5 M21 Mn4Ni1,5CrMo GMAW
Union X 90 Boggies/Waggons up to 890 Mpa YS A5.28: ER120S-G 16834-A: G 89 6 M21 Mn4Ni2CrMo GMAW
Union X 96 Boggies/Waggons up to 890 Mpa YS A5.28: ER120S-G 16834-A: G 89 5 M21 Mn4Ni2,5CrMo GMAW
diamondspark 700 MC Boggies/Waggons up to 690 Mpa YS A5.28/SFA-5.28: E110C-K4H4 18276-A: T 69 6 Mn2NiCrMo M M21 1 H5 MCAW
diamondspark 900 MC Boggies/Waggons up to 890 Mpa YS A5.28/SFA-5.28: E110C-K4H4 18276-A: T 89 5 ZMn2NiCrMo M M21 1 H5 MCAW
diamondspark 960 MC Boggies/Waggons up to 960 Mpa and higher YS 18276-A: T 89 4 ZMn2NiCrMo M M21 1 H5 MCAW
BÖHLER CN 23/12 PW-FD Waggons/Railcarbody Mixed joints austenitic - heat resistant A5.22: E309LT1-4/-1 17633-A: T 23 12 L P M21/C1 1 FCAW
Union S 2 + UV 306 Boggies/Rolling Stock up to 420 Mpa YS A5.17: F7A2-EM12-H4 14171-A: S 42 3 AR S2 H5 SAW
Union S 2 + UV 400 Boggies/Rolling Stock up to 420 Mpa YS A5.17: F7A4-EM12 / F6P4-EM12 14171-A: S 38 4 AB S2 SAW
Union S 3 Si + UV 418 TT Boggies/Rolling Stock up to 460 Mpa YS A5.17: F7A8-EH12K 14171-A: S 46 6 FB S3Si SAW
Union S 2 Mo + UV 418 TT Boggies/Rolling Stock up to 460 Mpa YS A5.17: F8A6-EA2-A2 14171-A: S 46 4 FB S2Mo SAW
diamondspark S 55 HP + UV 418 TT Boggies/Rolling Stock up to 460 Mpa YS A5.17: F7A8-EC1 / F7P8-EC1 14171-A: S 46 6 FB T3 H5 SAW_FCW
diamondspark S 55 HP + UV 306 Boggies/Rolling Stock up to 500 Mpa YS A5.17: F7A5-ECG-H4 14171-A: S 50 4 AR T3 H4 SAW_FCW
diamondspark S 56 HP + UV 400 Boggies/Rolling Stock up to 460 Mpa YS A5.17: F7A8-ECG 14171-A - S 46 6 AB TZ3 H5 SAW_FCW
Union S 3 NiMo 1 + UV 418 TT Boggies/Rolling Stock up to 550 Mpa YS A5.23: F9A8-EF3-F3 26304-A - S 55 6 FB S3Ni1Mo SAW
Union S 3 NiMoCr + UV 418 TT Boggies/Rolling Stock up to 690 Mpa YS A5.23: F11A8-EG-F6 26304-A - S 69 6 FB SZ3Ni2,5CrMo SAW
Union S 3 NiMoCr + UV 422 TT-LH Boggies/Rolling Stock up to 690 Mpa YS A5.23: F11A8-EG-F6-H4 26304-A - S 69 6 FB SZ3Ni2,5CrMo H4 SAW
diamondspark S 700 HP + UV 422 TT-LH Boggies/Rolling Stock up to 690 Mpa YS A5.23: F11A10-ECF5-F5 H4/ F11P6-ECF5-F5 H4 26304-A - S 69 6 FB TZ3Ni2,7CrMo H4 SAW_FCW
diamondspark S 770 + UV 422 TT-LH Boggies/Rolling Stock up to 770 Mpa YS A5.23: F12A6-ECF5-H4 26304-A - S 69 5 FB TZ H4 SAW_FCW
Böhler A 7 CN-IG Tank Construction 1.4370, 307Si A5.9: ER307 (mod.) 14343-A: G 18 8 Mn GMAW
Böhler EAS 2-IG ( Si) Tank Construction/Railcarbody 1.4306 304L A5.9: ER308LSi 14343-A: G 19 9 L Si GMAW
Böhler SAS 4-IG (Si) Tank Construction/Railcarbody 1.4627, 318Si A5.9: ER318 (mod.) 14343-A: G 19 12 3 Nb Si GMAW
FOXcore 307-MC Tank Construction/Railcarbody 1.4370, 307Si A5.22: EC307 (mod.) 17633-A: T 18 8 Mn M M12 1 MCAW
Böhler EAS 4-IG (Si) Tank Construction/Railcarbody 1.4404, 316L A5.9: ER316LSi 14343-A: G 19 12 3 L Si GMAW
FOXcore 316L-T1 Tank Construction/Railcarbody 1.4404, 316L A5.22: E316LT1-4(1) 17633-A: T 19 12 3 L P M21(C1) 1 FCAW
FOXcore 2307-T0 Tank Construction/Railcarbody LDX2101 A5.22: E2307T0-4(1) 17633-A: T 23 7 N L R M21(C1) 3 FCAW
FOXcore 2307-T1 Tank Construction/Railcarbody LDX2101 A5.22: E2307T1-4(1) 17633-A: T 23 7 N L P M21(C1) 1 FCAW
FOXcore 2307-T0 Tank Construction/Railcarbody LDX2304 A5.22: E2307T0-4(1) 17633-A: T 23 7 N L R M21(C1) 3 FCAW
FOXcore 2307-T1 Tank Construction/Railcarbody LDX2304 A5.22: E2307T1-4(1) 17633-A: T 23 7 N L P M21(C1) 1 FCAW
FOXcore 2209-T0 Tank Construction/Railcarbody LDX2205 A5.22: E2209T0-4(1) 17633-A: T 22 9 3 N L R M21(C1) 3 FCAW
FOXcore 2209-T1 Tank Construction/Railcarbody LDX2205 A5.22: E2209T1-4(1) 17633.A: T 22 9 3 N L P M21(C1) 1 FCAW
Thermanit 25/09 CuT Tank Construction/Railcarbody S32750/2507 A5.9: ER2594 14343-A: G 25 9 4 N L GMAW
Thermanit 22/09 Tank Construction/Railcarbody LDX2205/ S32205 A5.9: ER2209 14343-A: G 22 9 3 N L GMAW
Union AlMg 5 Air Buffers AlMg 5, 3.3555 A5.10: ER5356 18273-A: S Al 5356 (AlMg5Cr(A)) GMAW
Union AlMg 4,5 Mn Zr Railcarbody AlMg 4.5 Mn, 3.3547 A5.10: ER5087 18273-A: S Al 5087 (AlMg4.5MnZr) GMAW
Union AlMg 4,5 Mn Tank Construction AlMg 4.5 Mn, 3.3547 A5.10: ER5183 18273-A: S Al 5183 (AlMg4.5Mn0.7(A)) GMAW
Union AlMg 3 Tank Construction AlMg 3, 3.3535 A5.10: ER5754 18273: S Al 5754 (AlMg3) GMAW
Union AlSi 5 Tank Construction AlMgSi 0.5, 3.3206 A5.10: ER4043 18273-A: S Al 4043A (AlSi5(A)) GMAW
Avesta BlueOne Pickling Paste 130 Surface Treatment of Stainless Steels Pickling
Avesta RedOne Pickling Spray 240 Surface Treatment of Stainless Steels Pickling
Avesta Pickling Bath 302 Surface Treatment of Stainless Steels Pickling
Avesta Cleaner 401 Surface Treatment of Stainless Steels Cleaning
