MOLDMAX XL
Materion’s MoldMAX XL Alloy is a high strength copper mold alloy with good thermal conductivity. The alloy contains no beryllium and is available in sections as large as 12″ thick. The alloy’s hardness is comparable with AISI P-20 tool steel, but its thermal conductivity is two to three times higher.
MoldMAX XL Alloy typically machines faster than tool steels, and with appropriate machine tools, metal removal rates several times higher can be obtained.
Product Features:
- Excellent toughness
- Excellent wear resistance
- Excellent surface finish
- Good polishability
Applications:
- Injection mold cores and cavities
Technical Data
Chemical Analysis
| Nickel | Tin | Copper |
|---|---|---|
| 8.5 – 9.5 | 5.5 – 6.5 | Balance |
