BÖHLER W720 VMR
BÖHLER W720 VMR is not a classic hot work tool steel, but an ultra-high strength maraging steel. Compared to quenched and tempered steels, the material generates its high strength not through a hardened and tempered martensitic structure with a high carbon content and secondary hardening carbides, but through the precipitation of intermetallic phases from a tough nickel martensitic matrix. BÖHLER W720 VMR corresponds to material number 1.6358 (X2NiCoMoTi18-9-5) and has proven to be ideally suited for many tool steel applications in cold and hot work (e.g., for extrusion stems) up to 450 °C.
Applications:
- Extrusion
- High Pressure Die Casting (HPDC)
- Injection Molding
Technical Data
Chemical Analysis
| C | Si | Mn | Mo | Ni | Co | Ti | Al |
|---|---|---|---|---|---|---|---|
| ≤0,030 | ≤0,10 | ≤0,10 | 5.00 | 18.50 | 9.00 | 0.70 | 0.10 |
