Ductile Iron

Manufacturing Capability- Ductile

Also see Ductile Plates and BlueRoll

  • ISO 9001:2008
  • 16,000 tons annual melt capacity
  • Green sand molding
  • DISA Mark V-B molding line
    • 25.5” x 21” plate
  • Maximum part size: 23”x18”
  • Weight ranges: .5 lbs to 60 lbs
  • 200 to 300 molds per hour
  • Chemistry, microstructure and hardness verified onsite. Mechanical property certifications completed at an off-site laboratory.
  • Ductile Iron produced to ASTM A536
    • 60-40-18 (EN-GJS-400-18)
    • 65-45-12 (EN-GJS-450-10)
    • 80-55-06 (EN-GJS-500-7)
  • Gray Iron produced to:
    • CL25 (EN-GJL-150)
    • CL30 (EN-GJL-200)
  • Markets served: Railway, agriculture, mining, oil and gas
  • Value added: Machining, coating, heat treating, liquid penetrant inspection (LPI), magnetic particle inspection (MPI) and radiography on our parts upon request.
